PISTON KIT SHERCO 300 72.00, WOSSNER 8294DB2-STROKE

This Wossner 72.01mm bore forged piston kit (part number 8294DB, +0.01mm oversize) is precision-engineered for Sherco 2-stroke engines. With its high-strength forged construction and advanced thermal management design, it provides reliable performance and durability. The elliptical shape aids in balanced load distribution during heat expansion, reducing stress and wear on the piston. Made in Germany, this piston kit is suitable for long-term engine reliability.

Features

• Forged piston construction for superior strength and longevity

• Designed for optimal combustion heat transfer to cylinder walls

• Elliptical geometry ensures uniform bearing surface and load distribution

• Made in Germany

Specifications

• Bore: 72.01mm

• Bore Size: 71.94mm

• Compression Ratio: 2-Stroke (Wossner and OEM)

• Compression Height: 38.00mm

• Clearance: 0.07mm

• Stroke: 72.00mm

• Displacement: 249cm³

• Clip Part Number: CW18

• Piston Pin: WP033

• Ring Set: RSB7200

Cross-Reference OEM Part Numbers

• 56-W9878.B.WO

Vehicle Fitments

• Sherco 300SE (2013– )

• Sherco 300SE-R (2013–2016)
