PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX
  • PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX
  • PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX
PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX

PISTON KIT 89-95 RM250 68.00, WOSSNER 8022D100 SUZUKI MX

£154.18 GBP
Taxes included. Shipping calculated at checkout.

Piston 68mm Bore 67.94 Wossner 8022D100 (+1.00)

Suzuki
RM250 1989-1995,
RMX250 1993-1995,

  • Wossner forged pistons are superior in strength and design.
  • Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
  • Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
  • Made in Germany.

Part No. 56-W642_100.WO (oro2u.com)
Lock P/N CW18
Pin P/N WP033
Ring Set P/N RSB6800 x 2

Display (cm3) 246
Hub stroke (mm) 70.80
Clearance (mm) 0.06
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3)
Compression height (mm) 37.00
Theorectical weight (G)



Cross reference numbers ONLY.
PISTON 12110-28C11-0F0, 12110-29E20-0F0 , RING, PISTON 12141-41600, 12141-41620, PIN, PISTON 12151-28C00, 12151-37F00 , CIRCLIP 09381-18002,
