PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
  • PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
  • PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
  • PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
  • PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV
PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV

PISTON KIT 1987 LT250 67.50, WOSSNER 8258D050 SUZUKI ATV

£143.87 GBP
Taxes included. Shipping calculated at checkout.

Wossner Forged Piston Kit 67.50mm Bore – Suzuki LT250 1987 (8258D050 +0.50)
This Wossner forged piston kit is tailored for the 1987 Suzuki LT250 ATV, featuring a +0.50mm oversize bore (actual 67.44mm). Designed for enhanced performance in 2-stroke engines, it features forged construction for superior strength and thermal management. The elliptical shape of the piston ensures even thrust load distribution, reducing stress and risk of failure during high thermal expansion. Precision manufactured in Germany.

Features

  • Forged piston design for increased strength and longevity

  • Engineered for efficient heat dissipation from the combustion chamber

  • Elliptical profile ensures uniform bearing surface under heat expansion

  • Developed for 2-stroke engine use

  • Made in Germany

Specifications

  • Bore Size: 67.50mm (+0.50 oversize)

  • Actual Bore: 67.44mm

  • Compression Height: 37.20mm

  • Clearance: 0.06mm

  • Stroke: 70.00mm

  • Displacement: 246 cm³

  • Wossner Compression Ratio: 2-stroke

  • OEM Compression Ratio: 2-stroke

Cross-Reference OEM Part Numbers

  • Wossner Piston: 8258D050

  • Ring Set: RSB6750 (x2)

  • Lock: CW18

  • Pin: WP033

  • Internal Reference: 56-W577+0.50.WO

Vehicle Fitments

  • 1987 Suzuki LT250
