PISTON KIT 11-15 KTM350 88.00, FORGED WOSSNER 8807DB
£175.93 GBP
Taxes included.
Wossner forged piston kit designed for high-performance applications, offering superior strength and optimized heat transfer. The elliptical design ensures a uniform bearing surface under heat expansion, reducing localized pressure and preventing piston collapse. Manufactured in Germany for precision and durability.
Features
- Forged piston for enhanced strength and durability
- Optimized heat transfer to cylinder walls for improved performance
- Elliptical design for even thrust load distribution
- Manufactured in Germany
Specifications
- Bore Size: 88.01mm
- Actual Bore: 87.96mm
- Display (cm³): 229
- Stroke (mm): 53.60
- Clearance (mm): 0.05
- Wossner Compression Ratio: OEM
- OEM Compression Ratio: 13.20:1
- Dome Volume (cm³): +1.30
- Compression Height (mm): 20.50
- Theoretical Weight: N/A
- Lock Part Number: CW18
- Pin Part Number: WP053
- Ring Set Part Number: 880XSY
Rod Part Numbers:
- P4040 (2010-2012)
- P4061 (2013-2015)
- P4069 (2016)
- Part Number: 56-W4735+00B.WO
Vehicle Fitments
- KTM SX-F 350 2011-2015
