PISTON KIT 05-07 RMZ450 100.00, WOSSNER 8606D450 BIG BORE

PISTON KIT 05-07 RMZ450 100.00, WOSSNER 8606D450 BIG BORE

£175.93 GBP
Taxes included.

Wossner forged piston kit with a 100mm bore, designed for Suzuki RM-Z 450 models. Engineered for optimal combustion chamber heat transfer and uniform bearing surface under heat expansion, reducing localized pressure and piston collapse. Manufactured in Germany for durability and precision.

Features

  • Forged piston for superior strength and design
  • Optimized heat transfer to cylinder walls
  • Elliptical design for uniform bearing surface and even thrust load distribution
  • Manufactured in Germany

Specifications

  • Bore: 100mm (+4.50mm oversize)
  • Standard size piston (PN# 8606D450)
  • Lock Part Number: CW19
  • Pin Part Number: WP037
  • Ring Set Part Number: 1000XSY
  • Displacement: 449 cm³
  • Stroke: 62.60mm
  • Clearance: 0.04mm
  • Wossner Compression Ratio: OEM
  • OEM Compression Ratio: 12.00:1
  • Dome Volume: -3.10 cm³
  • Compression Height: 22.30mm

Cross-Reference OEM Part Numbers

  • Not provided

Vehicle Fitments

  • Suzuki RM-Z 450 (2005-2007)
