PISTON KIT 00-03 RM125 56.00, WOSSNER 8061D200 SUZUKI MX

This Wossner piston kit features a 56.00mm bore and is a +2.00mm oversize component tailored for the Suzuki RM125 model years 2000 through 2003. Constructed from high-strength forged material, it delivers enhanced thermal conductivity and structural integrity under demanding 2-stroke engine conditions.

Features

• Forged piston construction provides increased durability and fatigue resistance

• Optimised for efficient heat transfer from the combustion chamber to the cylinder wall

• Elliptical design maintains even load distribution during heat expansion

• Reduces risk of localised stress and piston collapse

• Manufactured in Germany with high precision

Specifications

• Bore: 56.00 mm

• Actual piston size: 55.95 mm

• Stroke: 54.50 mm

• Display volume: 125 cm³

• Clearance: 0.05 mm

• Compression ratio: 2-stroke (Wossner and OEM)

• Compression height: 29.50 mm

Cross-Reference OEM Part Numbers

• Piston Kit: 8061D200

• Lock: CW15

• Pin: WP032

• Ring Set: RSB5600

• Rod: P2013

• Part No: 56-W754.200.WO

Vehicle Fitments

• Suzuki RM125 2000

• Suzuki RM125 2001

• Suzuki RM125 2002

• Suzuki RM125 2003
