MINO REAR SPROCKET FUSION 2-RING, 23-612-49 BLACK STEEL/ALLOY

Part No. SR460-49.AF.BK (oro2u.com)

Fitment:

KAWASAKI
KX125 1980-2008
KX250 1982-2008
KX250F 2004-2023
KX450F 2006-2023
KX450X 2022-2023
KLX450R 2008-2009
KX500 1983-2004
KDX175 1979-1985
KDX200 1986-2006
KDX220 1997-2005
KDX250 1984 / 1991-1993
KLX250 1979-1994
KLX250 G1,G2 1994-1998
KLX250 R E1,E2,E3 1991-1995
KLX250 R D1,D2,D3,D4 1993-1999
KLX250 S H6F,H7F 2006-2007
KLX250S T9F,TAF,TBF,TCF,TDF,TEF,TFF 2009-2015
KLX250 SF,W9F,WAF 2009-2010
KLX250 S9F,SAF-SHF 2009-2019
KLX250 S SKFA 2019
KLX300R 2003-2008
KLX300 1997-2003
KLX300 A8,A9,A10,A6F,A7F (KLX300R) 2003-2007
KLX450R 2008-2019
KDX420 1980
KLX650 1993-1996

SUZUKI
RM-Z 250 2004-2006

FUSION 2-RING CHAIN WHEEL REAR SPROCKET Steel+Alloy.
The longest lasting most durable off-road sprocket you can buy.
The unique flat face design keeps weight to a minimum and means the 2-RING FUSION is as narrow as a regular sprocket.
Inner Ring is high strength Ultralight 7075 T6 Aluminium. Outer Ring is Nickel Coated steel.
Outer is expanded at 200 °C and then fitted to inner, creating a permanent fusion friction bond for the life of the sprocket.

FUSION SERIES FEATURES

> Inner ring in 7075 aluminum and special hardened steel outer ring combine low weight with maximum lifespan.

> CAD designed, CNC machined and laser cut using state of the art technology.

> Precise manufacturing interlocks both rings, eliminates all movement.

> Sector optimized layout for maximum strength and lowest weight.

> Inner ring is color anodized coated for extra strength and durability.

> Race proven on the toughest sand tracks in the Netherlands & Belgium.
