Connecting Rod KTM SX-F250, Hot Rods 8701 77730015144

Connecting rod kit for KTM 250 SX-F, XC-F, and XCF-W models, designed as a heavy-duty OE replacement. Manufactured in the USA using certified 8620 AISI steel for superior strength and durability, this kit is compatible with Hot Rods and OE crankshafts. It includes all components needed for a reliable rebuild.

Features

• Heavy-duty OE replacement connecting rod.
• Constructed from certified 8620 AISI steel for exceptional durability.
• Unique big-end design features side scalloping and vent slots to reduce high-rpm bearing race distortion.
• Crankpins are hot-rolled ASTM 4115 steel and case-hardened to 58-62Rc for enhanced strength.
• Caged needle roller bearing designs ensure longevity at high rpm.
• Thrust washers made from bronze phosphor with a silver coating for added performance.
• Complete kit includes rod, crankpin, crankpin bearing, top-end bearing, and thrust washers.
• Compatible with both Hot Rods and OE crankshafts.
• Made in the USA.

Included Items

• (1) Connecting rod
• (1) Crankpin
• Instructions

Cross Reference OEM Part Numbers

• Athena P40321043
• 77730015144
• Psychic MX-09022
• Hotrods 8701
• ProX 03.6333
• Wossner P4059
• 777.30.015.144

Vehicle Fitments

KTM

• 250 SX-F: 2003–2015
• 250 XC-F: 2013–2015
• 250 XCF-W: 2015–2016
• 350 SX-F: 2013–2015
