CONNECTING ROD 85-87 CR125
£69.58 GBP
Taxes included.
HONDA
CR125R 1985-1987,
CONNECTING CONROD ROD REBUILD KIT. PSYCHIC MX-09003
- Heavy-duty OE replacement connecting rods.
- Certified Chorme alloy steel provides superior strength.
- Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
- Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
- Thrust washers are manufactured from bronze phosphor and are silver coated.
- Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
- Fully Compatible with after market and OE crankshafts.
- Material SNCM220,
| SIZE | MM |
| Centre 2 Centre | 104 |
| Small End Bearing | 14x19x18.7 |
| Small End Bore Ø | 19 |
| Small End Width | 16 |
| Big End Bearing | 22x28x16 |
| Big End Bore Ø | 28 |
| Big End Width | 16 |
| Big End Pin Ø | 22 |
| Big End Pin Length | 53.80 |
| Washer Thickness | 22x37x1.0 |
Part No. 56-930.DR (oro2u.com)
Cross reference numbers ONLY.
13200-KA3-760 HONDA: 13200-KS6-305, 13200-KS6-306, HOTRODS 8161, 30.1212,
