CONNECTING ROD +5 RA-40000 AT-09134, 86-07 BANSHEE LONG ROD +5mm

This connecting rod rebuild kit is designed as a +5mm heavy-duty OE replacement for the Yamaha YFZ350 Banshee (Long Rod) models from 1987 to 2006. Manufactured from certified chrome alloy steel (SNCM220), it includes all necessary components for a complete rod assembly and is fully compatible with both aftermarket and OE crankshafts.

Features

• Heavy-duty OE replacement connecting rod

• Certified chrome alloy steel (SNCM220) provides superior strength

• Crankpins manufactured from hot-rolled ASTM steel and case hardened

• Thrust washers made from bronze phosphor and silver coated

• Complete rod assembly includes rod, crankpin, crankpin bearing, top end bearing, and thrust washers (if needed)

• Fully compatible with aftermarket and OE crankshafts

Specifications

• Centre to Centre: 115 mm

• Small End Bearing: 16x21x22.3 mm

• Small End Bore Diameter: 21 mm

• Small End Width: 17.90 mm

• Big End Bearing: 22x29x17 mm

• Big End Bore Diameter: 22 mm

• Big End Width: 17 mm

• Big End Pin Diameter: 29 mm

• Big End Pin Length: 52.70 mm

• Washer Thickness: 22.20x36.90x1.00 mm

Cross-Reference OEM Part Numbers

• Yamaha: 29L-11651-00-00

• Hot Rods: 8158

Vehicle Fitments

• Yamaha YFZ350 Banshee (Long Rod) 1987–2006
