Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
  • Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005
Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005

Wrist Pin Bearing 76-06 Kawasaki Suzuki Kdx KX RM 125 175 200 220 16x21x19.5 Vintco BNW005

£19.82 GBP
Taxes included. Shipping calculated at checkout.

VintCo BNW005 is a wrist pin bearing for vintage Kawasaki and Suzuki dirt bike applications, intended for top-end engine work. It uses a modern extended shoulder design and is manufactured with modern materials and production methods for OEM-style fitment and performance. The supplied manufacturer description states Kawasaki KX125 1980-1981 fitment, with additional Kawasaki KDX and Suzuki RM applications listed below.

Features

  • Wrist pin bearing for top-end engine rebuild work
  • Suitable for vintage dirt bike applications
  • Modern extended shoulder design
  • Stronger than 1970s wrist pin bearing designs
  • Manufactured using modern materials and manufacturing techniques
  • Intended to provide OEM-equivalent or better fitment and performance
  • Fits multiple Kawasaki and Suzuki models
  • Manufacturer description states Kawasaki KX125 1980-1981 fitment

Specifications

  • VintCo Part Number: BNW005
  • Item Category: Wrist Pin Bearing
  • Bearing Size: 16 x 21 x 19.5

Cross-Reference OEM Part Numbers

  • Kawasaki: 13033-1007
  • Suzuki: 09263-16015

Vehicle Fitments

  • 1976 Suzuki RM125
  • 1980 Kawasaki KDX175
  • 1981 Kawasaki KX125
  • 1981 Kawasaki KDX175
  • 1982 Kawasaki KX125
  • 1982 Kawasaki KDX175
  • 1983 Kawasaki KX125
  • 1983 Kawasaki KDX200
  • 1984 Kawasaki KX125
  • 1984 Kawasaki KDX200
  • 1985 Kawasaki KX125
  • 1985 Kawasaki KDX200
  • 1986 Kawasaki KX125
  • 1986 Kawasaki KDX200
  • 1987 Kawasaki KX125
  • 1987 Kawasaki KDX200
  • 1988 Kawasaki KX125
  • 1988 Kawasaki KDX200
  • 1989 Kawasaki KX125
  • 1989 Kawasaki KDX200
  • 1990 Kawasaki KX125
  • 1990 Kawasaki KDX200
  • 1991 Kawasaki KX125
  • 1991 Kawasaki KDX200
  • 1992 Kawasaki KX125
  • 1992 Kawasaki KDX200
  • 1993 Kawasaki KX125
  • 1993 Kawasaki KDX200
  • 1994 Kawasaki KDX200
  • 1995 Kawasaki KDX200
  • 1996 Kawasaki KDX200
  • 1997 Kawasaki KDX200
  • 1997 Kawasaki KDX220
  • 1998 Kawasaki KDX200
  • 1998 Kawasaki KDX220
  • 1999 Kawasaki KDX200
  • 1999 Kawasaki KDX220
  • 2000 Kawasaki KDX200
  • 2000 Kawasaki KDX220
  • 2001 Kawasaki KDX200
  • 2001 Kawasaki KDX220
  • 2002 Kawasaki KDX200
  • 2002 Kawasaki KDX220
  • 2003 Kawasaki KDX200
  • 2003 Kawasaki KDX220
  • 2004 Kawasaki KDX200
  • 2004 Kawasaki KDX220
  • 2005 Kawasaki KDX200
  • 2005 Kawasaki KDX220
  • 2006 Kawasaki KDX200
