WRIST PIN BEARING 73-86 HONDA KAWASAKI SUZUKI CR KE KD KS KX MT RM RV 125 14X18X20 VINTCO BNW002

WRIST PIN BEARING 73-86 HONDA KAWASAKI SUZUKI CR KE KD KS KX MT RM RV 125 14X18X20 VINTCO BNW002

£19.82 GBP
Taxes included. Shipping calculated at checkout.

VintCo BNW002 is a wrist pin bearing for a range of vintage Honda, Kawasaki and Suzuki 125 models from 1972 to 1986. It is intended for top-end engine service and is manufactured using modern materials and production techniques, with an extended shoulder design for a stronger bearing layout than earlier 1970s designs. This 14 x 18 x 20 bearing covers many popular applications, including Honda CR125 and MT125, Kawasaki KX125, KD125, KE125 and KS125, and Suzuki RM125, RV125 and TC125 models.

Features

  • Replacement wrist pin bearing for vintage 125 models
  • Intended for top-end engine work
  • Extended shoulder design
  • Stronger design than earlier 1970s wrist pin bearing layouts
  • Manufactured using modern materials and production techniques
  • Designed for OEM-style fitment and performance

Specifications

  • VintCo Part Number: BNW002
  • Product Type: Wrist Pin Bearing
  • Bearing Size: 14 x 18 x 20

Cross-Reference OEM Part Numbers

  • Honda: 91007-444-004
  • Suzuki: 09263-14022
  • Suzuki: 09263-14024
  • Kawasaki: 13033-035

Vehicle Fitments

  • 1972 Suzuki TC125
  • 1973 Suzuki TC125
  • 1973 Suzuki RV125
  • 1974 Honda CR125
  • 1974 Kawasaki KX125
  • 1974 Kawasaki KS125
  • 1974 Suzuki TC125
  • 1974 Kawasaki KD125
  • 1974 Kawasaki KE125
  • 1974 Suzuki RV125
  • 1974 Honda MT125
  • 1975 Honda CR125
  • 1975 Kawasaki KX125
  • 1975 Suzuki RM125
  • 1975 Kawasaki KD125
  • 1975 Kawasaki KS125
  • 1975 Suzuki TC125
  • 1975 Kawasaki KE125
  • 1975 Suzuki RV125
  • 1975 Honda MT125
  • 1976 Honda CR125
  • 1976 Kawasaki KX125
  • 1976 Kawasaki KD125
  • 1976 Suzuki TC125
  • 1976 Kawasaki KE125
  • 1976 Suzuki RV125
  • 1976 Honda MT125
  • 1977 Honda CR125
  • 1977 Suzuki RM125
  • 1977 Kawasaki KD125
  • 1977 Kawasaki KE125
  • 1977 Suzuki TC125
  • 1977 Suzuki RV125
  • 1977 Honda MT125R
  • 1978 Honda CR125
  • 1978 Suzuki RM125
  • 1978 Kawasaki KD125
  • 1978 Kawasaki KE125
  • 1978 Honda MT125R
  • 1979 Honda CR125
  • 1979 Suzuki RM125
  • 1979 Kawasaki KD125
  • 1979 Kawasaki KE125
  • 1980 Honda CR125
  • 1980 Suzuki RM125
  • 1980 Kawasaki KE125
  • 1981 Honda CR125
  • 1981 Kawasaki KE125
  • 1981 Suzuki RM125
  • 1982 Kawasaki KE125
  • 1982 Suzuki RM125
  • 1982 Honda CR125
  • 1983 Kawasaki KE125
  • 1983 Suzuki RM125
  • 1983 Honda CR125
  • 1984 Honda CR125
  • 1984 Suzuki RM125
  • 1985 Suzuki RM125
  • 1986 Suzuki RM125
