TOP END PISTON KIT 88-90 SUZUKI LT R 500 87mm 1.0mm OVER VINTCO KTS30-1.0

TOP END PISTON KIT 88-90 SUZUKI LT R 500 87mm 1.0mm OVER VINTCO KTS30-1.0

£225.72 GBP
Taxes included. Shipping calculated at checkout.

This top end piston kit is for 1988-1990 Suzuki LT500R models and includes an 87 mm, 1.0 mm oversize forged piston with MOS2 coating for break-in, together with the required top end gaskets and a wrist pin bearing. The kit is priced at a 10% discount compared with the individual items.

Features

  • Top end piston kit for Suzuki LT500R models
  • Forged piston
  • Made in Germany
  • MOS2 coated for break-in
  • Includes cylinder head gasket
  • Includes cylinder base gasket
  • Includes intake gasket
  • Includes exhaust pipe gasket
  • Includes cylinder cover gasket
  • Includes wrist pin bearing

Specifications

  • VintCo Part Number: KTS30-1.0
  • Piston size: 87 mm
  • Oversize: 1.0 mm over
  • Piston measurement: 86.91 mm
  • Clearance: 0.09 mm

Cross-Reference OEM Part Numbers

  • Cylinder Head Gasket: OE# 11141-43B30
  • Cylinder Base Gasket: OE# 11241-43B10
  • Intake Gasket: OE# 13156-01C10
  • Exhaust Pipe Gasket: OE# 14181-43B01
  • Cylinder Cover Gasket: OE# 11233-01C00

Vehicle Fitments

  • 1988 Suzuki LT500R
  • 1989 Suzuki LT500R
  • 1990 Suzuki LT500R
