TOP END PISTON KIT 88-90 SUZUKI LT R 500 87.5mm 1.5mm OVER VINTCO KTS30-1.5

This top end piston kit is for 1988-1990 Suzuki LT500R models and includes the core components required for a top end rebuild. The kit includes a forged piston made in Germany with an MOS2 coating for break-in, along with the required cylinder head, base, intake, exhaust pipe and cylinder cover gaskets, plus a wrist pin bearing. Kit pricing includes a 10% discount compared with purchasing the items individually.

Features

• Top end piston kit for Suzuki LT500R models
• Includes forged piston
• MOS2 coated for break-in
• Made in Germany
• Includes cylinder head gasket
• Includes cylinder base gasket
• Includes intake gasket
• Includes exhaust pipe gasket
• Includes cylinder cover gasket
• Includes wrist pin bearing
• Kit price includes a 10% discount over individual items

Specifications

• VintCo Part Number: KTS30-1.5
• Piston size: 87.5 mm
• Oversize: 1.5 mm over
• Piston measurement: 87.41 mm
• Clearance: 0.09 mm

Cross-Reference OEM Part Numbers

• Cylinder Head Gasket: 11141-43B30
• Cylinder Base Gasket: 11241-43B10
• Intake Gasket: 13156-01C10
• Exhaust Pipe Gasket: 14181-43B01
• Cylinder Cover Gasket: 11233-01C00

Vehicle Fitments

• 1988 Suzuki LT500R
• 1989 Suzuki LT500R
• 1990 Suzuki LT500R
