SPOKE SET 17"x36 YAMAHA XTZ 750 89-96, CROSS CENTER 50-0505

SPOKE SET 17"x36 YAMAHA XTZ 750 89-96, CROSS CENTER 50-0505

£100.93 GBP
Taxes included. Shipping calculated at checkout.

Stainless steel spoke set designed for Yamaha XTZ 750 models from 1989 to 1996, intended for cross centre lacing on 17-inch rear wheels. The set includes 36 spokes with matching nipples and is configured for compatibility with specific rear hub and rim combinations.

Features

  • Complete spoke set for rear wheel assembly

  • Designed for cross centre lacing pattern

  • Includes 36 spokes with corresponding spoke nipples

  • Compatible with 17 x 3.00 and 17 x 3.50 rear wheels

  • Suitable for use with rear hub 3LD-25311-00-98 and replacement 3LD-25311-01-98

  • Compatible with 17 x 3.00 Excel rim (article number 58-741)

  • Compatible with 17 x 3.50 Excel rim (article number 58-742)

  • Individual replacement spoke and nipple sets available

Specifications

  • Article number: 50-0505

  • Total spokes: 36

  • Left side spokes: 18 pcs, 3.6 x 131 mm

  • Right side spokes: 18 pcs, 3.6 x 179 mm

  • Spoke material: stainless steel

  • Nipple size: 6.5 x 20 mm (9G/250)

  • Individual spoke (left) article number: 50-0505-1

  • Individual spoke (right) article number: 50-0505-2

Cross-Reference OEM Part Numbers

  • 3LD-25304-00 (Spoke Set)

Vehicle Fitments

  • Yamaha XTZ 750 (1989–1996)
