Piston Kit 83-88 500 87.50mm, Wossner 8037D150 Husqvarna

Piston kit 87.50mm Bore 87.42 Wossner 8037D150   (+1.50)

Husqvarna
CR 500 1983 - 1987,

• Wossner forged pistons are superior in strength and design.
• Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls.
• Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse.
• Made in Germany.

PART NO. 56-W091+1.50
Wossner Piston Husqvarna CR500 87.50 mm Bore (PN# 8037D150)
Lock P/N CW20
Pin P/N WP086
Ring Set P/N RSC8750

Display (cm3) 500
Hub stroke (mm) 84.00
Clearance (mm) 0.08
Wossner compression Ratio: 2 stroke
OEM Compression ratio: 2 stroke
Dome volume (cm3) -
Compression height (mm) 42.00
Theorectical weight (G)
