PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
  • PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5
PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5

PISTON KIT 78-80 SUZUKI RM 400 81.5mm 1.5mm OVER VINTCO PSS05-1.5

£182.36 GBP
Taxes included. Shipping calculated at checkout.

VintCo PSS05-1.5 is a piston kit for 1978-1980 Suzuki RM400 models, intended for vintage 2-stroke engine service. The kit includes the piston, rings, pin and clips, and is produced in Germany using modern materials and manufacturing methods for OEM-equivalent or improved fitment and performance. This version is a forged, MoS2-coated 81.5 mm piston at +1.5 mm oversize; a wrist pin bearing is available separately and additional size options are also available.

Features

  • Complete piston kit with piston, rings, pin and clips
  • Intended for vintage 2-stroke engine service
  • Designed for OEM-equivalent or improved fitment and performance
  • Coated to assist running-in
  • Wrist pin bearing sold separately
  • Additional size options available

Specifications

  • VintCo Part Number: PSS05-1.5
  • Bore Size: 81.5 mm
  • Oversize: +1.5 mm
  • Piston Diameter: 81.43 mm
  • Clearance: 0.07 mm
  • Construction: Forged
  • Coating: MoS2
  • Country of Manufacture: Germany

Vehicle Fitments

  • 1978 Suzuki RM400
  • 1979 Suzuki RM400
  • 1980 Suzuki RM400
